Combi Rail Pro Light Picture Rail + Fastener Kit Includes Free Mounting Kit (Saveup to $14.31)

Price range: $10.23 through $92.06

Combi Rail Pro Light is a wall-mounted picture rail with built-in lighting, rated to 50 kg per metre. Hang and illuminate your pictures with one clean track – supplied Australia-wide by Hang Logic, the authorised ArtiTeq partner.

    • Load capacity: 50 kg / m (pictures + lights)
    • Rail sizes: 2 m & 3 m long tracks,  profile:  25 mm h × 8.5 mm d
    • Colour: white
    • Lighting arms: 50 cm & 70 cm with twist-angle LED fittings
    • Fastener kit: 3 × Click & Connect clips per metre, plugs, screws, 2 end-caps
    • System elements: rail, live end, corner / straight connectors · light arms
    • Extra parts: transformer (specified by electrician) + GU10 or MR16 LED globes
    • Shipping: in stock – dispatches daily from our Adelaide warehouse

Prices

      • 40.11200 Combi Rail Pro Light 2 m + FREE Fastener Kit – $61.35
      • 40.11300 Combi Rail Pro Light 3 m + FREE Fastener Kit – $92.06
      • 40.31500 Live End (power feed) – $37.20
      • 40.31300 Straight & Corner Connector Set- $10.23
      • 40.21500 Light Arm 50 cm – $62.19
      • 40.21700 Light Arm 70 cm – $74.82
Read more

Combi Rail Pro Light picture rail- how to install it?

Mark a level line. Fix Click & Connect clips at 3 clips / m (6 for 2 m, 9 for 3 m). Drill Ø 6 mm, plug, screw, then click the rail onto the clips and tap on the live-end cap. Connect transformer wiring, add end-caps, done. Rails can be cut with drop saw to custom length.

What components do I need?

Rail, live end, connector set – if longer than 3 m (includes both straight and corner connectors for joining individual picture rails.),  50 cm or 70 cm light arms – these are supplied  by Hang Logic. In addition, you’ll need to buy a transformer sized above your total lamp wattage, and GU10 or MR16 LEDs.

Live End Cap Coverage?

One live end cap is sufficient for up to 8 meters of continuous hanging rails.

How do I add another rail or turn a corner?

Slide a straight or 90-degree connector (included in the connector set) into the metal strip channel, tap flush, then clip the next rail. The insulation plate ensures power stays in the strip.

Should I choose 50 cm or 70 cm light arms?

50 cm light arms = focused spread for small works.
70 cm = wider throw for big canvases or to wash a wall. Both arms twist at the lamp head for fine-angle control.

Which transformer should I buy?

A licensed electrician should specify a 24V DC transformer whose wattage capacity exceeds the total load of  the lights on your rail run.

What’s better – an in-wall or a plug-in transformer?

It depends on your set-up. You can hard-wire a 24 V DC transformer behind the wall (your electrician hides it and connects the rail’s two wires directly), or use a plug-in 24 V DC power supply. With a plug-in unit you cut off the round DC plug, strip the two leads, then join them to the rail’s red (+) and black (–) wires. An electrician should still make the final connection to keep it safe and to code.

Combi Rail Pro Light vs Click Rail Pro?

Combi adds a 12/24 V lighting channel and movable light arm fittings; Click Rail Pro only lets you hang pictures but carries the same 50 kg / m.

Related reading: Installing the Combi Rail Pro Light Picture Rail · Optimal Picture Hanging Height



Installation Sheet

View Installation Guide

Rail Installation Video

Rails are just the beginning. To hang your pictures you'll also need wires and hooks.

Hang Logic Google Reviews

Preferred worldwide by builders, architects, and professionals.

Excellent
Hang Logic
Based on 78 reviews
See all reviews
review us on
Samuel Jensen
Lorraine Hodgson
The rails arrived very safely and the 3m ones are now installed. The 2m one will be installed later in the house once we have finished renovating. As promised I have attached a few photos of my art studio space. I didn’t order enough to ensure there are two wires per canvas so would like to order more. I’m so impressed with the system that I want to use the hanging loops in the house.
JO Finnigan
Jacqueline at Hang Logic was super helpful with my project to hang a large rug I wanted to display but also flex to use as a curtain across a media room entryway. She spent time talking through the details and organised everything I needed from the Artiteq range. Fantastic customer service and great products! Very happy with the outcome
Dennis Lok
Great products and service, thank you!
Stuart Nagel
we have got sick of having to drill new holes every time we want to change over a picture. after looking at several other systems we tried hang logic and liked the ease of installing and using, it enables us to rotate art easily and simply so have ordered more to put in most rooms, would highly recommend if you are hanging art

some of Our CLIENTs

VIC - The Lume Melbourne
NSW - German International School
QLD - Brisbane Convention and Exhibition Centre
ACT- Adina Hotel Canberra
WA - WA Maritime Museum
SA - Adelaide Festival Centre

Related products

Artiteq Fastener Kit for 3m Click Rail Pro picture rail, available at Hang Logic, featuring clips, screws, plugs, and end caps for wall mounting.

Fastener Kit Click Rail Pro 300 cm Alu

$14.31
Add to cart
Perlon + Loop 2 mm

Perlon + Loop 2 mm

Price range: $4.60 through $6.31

Pre-looped - just slip it on

Select options This product has multiple variants. The options may be chosen on the product page
Coiled clear perlon Solid Slider hanging wire with steel T‑head for end‑insertion into a picture rail, supplied by Hang Logic.

Solid Slider 2 mm Dropper Cable

Price range: $5.10 through $32.42

Slides in from the side - suit fixed display

Select options This product has multiple variants. The options may be chosen on the product page
Partition hook

Wall Hook

Price range: $1.11 through $1.80

For top edges - partitions, panels, or nib walls.

Select options This product has multiple variants. The options may be chosen on the product page
ArtiTeq Shadowline Masonry picture rail with 13 mm capture, install diagram, section profile and build‑site photo

Shadowline Masonry Picture Rail

$67.98
Add to cart
Close‑up of white ArtiTeq Click Rail PRO picture rail with 10‑year warranty badge, 50 kg/m rating and free fastener kit
